LK7022

Electronic level sensor

For the reliable level control in tanks and containers

Suitable for water, oils and coolants

Clearly visible 4-digit LED display

Number of digital outputs: 2
Probe length L: [mm]264

Special feature:Gold-plated contacts
Mediahydrous coolants; oils; oil-based media; water; media similar to water
Dielectric constant of the medium> 2

Maximum speed of the change of level: [mm/s]100

Operating voltage: [V]12...30 DC
Current consumption : [mA]< 50
Protection : classIII
Reverse polarity protection yes
Power-on delay time : [s]< 3
Measuring principle capacitive

Total number of outputs l 2
Output signal switching signal; IO-Link
Electrical design : PNP/NPN
Output function :normally open / normally closed; (parameterisable)
Max. voltage drop switching output : DC[V]2.5
Permanent current rating of switching output :  DC[mA]200
