سطح سنج غیر تماسی آلتراسونیک

1 Millimeter Resolution
℃Stable output from -15℃ to +60
2.0MHz frequency ultrasonic sensor,High solid penetration, suitable for containers made by metal, plastic and other materials
Various connection type formats: UART serial port output
Dead band 5cm
Max ranging measurement 200cm
Working voltage 3.3-12.0Vdc, 12-36.0Vdc
Working current ＜35.0mA
Measurement accuracy：±(1+S*0.5%)，S stands for measured distance
Measuring container thickness 0.6-5mm
Small size, Light weight module
Operating temperature -15°C to +60°C
IP67 protection
