پروکسی سوئیچ غیر تماسی مایعات

DC input voltage(Vin) (DC 5-24V)
output method high&low level
consumption current ≤5mA
output voltage(high level) Vin
output voltage(low level) 0V
output current ≤100mA
response time 500mS
℃working temperature -20~105
Sensing distancesensed pipe OD(mm)sensed container thickness L(mm)
D≥10020  ± 2
100>D≥8015  ± 2
80>D≥6012  ±  1.5
60>D≥407  ±  1.0
40>D≥305  ±  1.0
30>D≥203  ±  1.0
20>D≥101.5  ± 0.5
applicable pipe OD≥10mm
level accuracy±1.5mm
humidity5%~100%
materialPC V0 fireproof
waterproof IP67
