PCI-6032E

100 kS/s, 16-Bit, 16-Analog-Input Multifunction DAQ

Product Family Multifunction Data Acquisition

Channels 16 , 8
Single-Ended Channels 16
Differential Channels 8
Resolution 16 bits
Sample Rate 100 kS/s
Max Voltage 10 V
Maximum Voltage Range -10 V , 10 V
Maximum Voltage Range Accuracy 1.147 mV
Minimum Voltage Range 0 mV , 100 mV
Minimum Voltage Range Accuracy 0.059 mV
Number of Ranges 14
Simultaneous Sampling No
On-Board Memory 512 samples

Bidirectional Channels 8

Counters 2
Number of DMA Channels 1
Buffered Operations Yes
Debouncing/Glitch Removal No
GPS Synchronization No
Maximum Range 0 V , 5 V
Max Source Frequency 20 MHz
Minimum Input Pulse Width 10 ns
Pulse Generation Yes
Resolution 24 bits
Timebase Stability 100 ppm
Logic Levels TTL
