سنسورفیبر نوری با نور قابل رویت قرمز

Product Model: FF-06R
Product Name: Optical Fiber Sensor (Standard Type)
Emitter : Red LED
Protection Class: IP65
Connection Method: 4 Cores / 5.0φ × 2 m Cable
Operating Voltage: 11–30VDC (ripple ≤20% p-p)
Max. Current Consumption: 40mA
Output Current: 150mA (max drive)
Response Time (ON / OFF): 0.1 / 0.15ms
Hysteresis: ≤5% of sensing distance
Illumination: Lamp ≤5000 / Sunlight ≤10000Lux
Operating Temperature: -20 ~ +70°C
Humidity Range: 35% ~ 85%Non-condensing
Housing Material: PBT
